0ms Transfer Time High Frequency UPS 32KW / 40 KVA Online UPS Enterprise Grade

Ideal Deployment Scenarios:

1. Hyperscale Data Centers - Protects high-density server racks
2. Industrial Manufacturing - Ensures continuous production line operation
3. Healthcare Facilities - Safeguards critical diagnostic imaging systems
4. Broadcast Studios - Prevents equipment damage from power anomalies

Technical Parameters:

Unmatched Power Stability for Critical Loads

1. Advanced Double-Conversion UPS Technology

• Pure Sine Wave Output (THD <2%) - Delivers clean power for sensitive medical/industrial equipment
• Wide Input Voltage Window (285-475VAC) - Handles severe grid fluctuations without battery drain
• Precision Voltage Regulation (±1%) - Maintains stable output during 100% load transitions

2. Intelligent Power Management Features

• Active PFC (PF >0.99) - Reduces energy costs and electrical infrastructure requirements
• Dynamic Frequency Tracking (±1Hz/S) - Ensures seamless generator compatibility
• 3:1 Crest Factor Support - Handles high inrush currents from servers and motors

3. Robust Protection Architecture

• Multi-Level Safeguards:

1. Short-circuit/overload protection (up to 160% capacity)
2. Battery overcharge/under-voltage prevention​

• Zero-Transfer Static Bypass - Maintains power during internal faults
• Hot-Swap Maintenance Bypass - Enables servicing without downtime

​

4. Enterprise Monitoring Capabilities

• Interactive LCD Display - Real-time visualization of load/kVA metrics
• Dual Communication Ports - RS485 + SNMP for network integration
• Expandable Battery Monitoring - Optional cell-level voltage/temperature tracking

Engineered for Extreme Reliability:

• IP42-rated enclosure for dust protection
• -40°C to +70°C storage range
• 85% load capacity at 40°C ambient

Available in:

• N+1 redundant configurations
• Custom battery cabinets for extended runtime

Compliant with IEC 62040-3 Class 1 standards for voltage/frequency variation.

Support and Services:

The High Frequency UPS product is designed to provide reliable and efficient power protection for critical equipment. Our technical support team is available to assist with any product inquiries or issues that may arise. Our services include:

• 24/7 technical support hotline
• Remote monitoring and diagnostics
• Preventative maintenance and inspections
• Emergency repair services
• Training and education on product use and best practices

We are committed to ensuring the uptime and performance of your critical equipment, and our technical support and services are designed to help you achieve that goal.

Product Packaging:

• High Frequency UPS unit
• Power cord
• User manual
• Warranty card

​
