High Frequency Online UPS - Premium Power Protection Solution For Financial Institutions

1 set
MOQ
Negotiation
Price
High Frequency Online UPS - Premium Power Protection Solution For Financial Institutions
Features Gallery Product Description Request A Quote
Features
Specifications
LCD Display: Real-time Status Monitoring
RS232/RS485: Yes
Control System: MCU+DSP
Capacity: 15KVA / 12KW
Form Factor: Tower
Highlight:

High Frequency Backup Ups

,

Ups Power Supply For Banks

,

Financial Institutions Ups Power Supply

Basic Infomation
Place of Origin: Shenzhen,China
Brand Name: Daxin
Certification: ISO9001,CE,3C,FCC,TLC,IP55
Model Number: 3H15KL
Payment & Shipping Terms
Packaging Details: Woodcase
Delivery Time: 20-40 days
Payment Terms: T/TD/A,Western Union,Paypal,etc
Supply Ability: 3000pcs/month
Product Description

High Frequency Online UPS - Premium Power Protection Solution For Financial Institutions

True Online Double Conversion UPS for Mission-Critical Applications

The 3H15KL Industrial Online UPS delivers 15KVA/12KW of reliable power protection through true online double conversion technology. Designed for demanding environments, this three-phase input UPS ensures continuous operation for critical systems.



Key Benefits:



  • Uninterrupted Power Supply: True online double conversion ensures zero transfer time
  • Flexible Configuration: Adjustable battery banks and charging current
  • Enhanced Reliability: Multiple protection mechanisms
  • Easy Maintenance: Optional bypass for uninterrupted service
  • Wide Compatibility: Works with generators and various loads



Applications:



  • Data Centers: Continuous power for servers and network equipment
  • Medical Facilities: Protection for sensitive medical equipment
  • Industrial Systems: Reliable power for automation and control systems
  • Telecommunications: Stable power for base stations and network infrastructure



Technical Parameters:



Parameter Specification
Model 3H15KL
Capacity 15KVA / 12KW
Input Voltage 190-520VAC (three-phase)
Output Voltage 208/220/230/240VAC (±1%)
Frequency Range 46-54Hz (50Hz)/56-64Hz (60Hz)
Transfer Time 0ms (AC↔Battery/Bypass)
Waveform Pure Sine Wave
Efficiency >89% (AC mode), >86% (battery mode)
Operating Temp 0-40°C
Noise Level <58dB @ 1m
Parallel Capability Up to 3 units (specific models only)



Core Features:



1. Advanced Power Protection



  • True online double conversion with 0ms transfer time
  • Pure sine wave output (≤2% THD for linear loads)
  • Wide input voltage range: 190-520VAC (three-phase)
  • Generator compatible (requires 2x UPS capacity)



2. Intelligent System Design



  • MCU+DSP dual control system
  • Configurable battery banks (16-20 cells)
  • Adjustable charging current (1-4A default)
  • Automatic restart after power recovery

High Frequency Online UPS - Premium Power Protection Solution For Financial Institutions 0



3. Comprehensive Protection



  • Multi-level safeguards:
  • Output overload protection
  • Short circuit protection
  • Inverter over-temperature protection
  • Battery under-voltage warning
  • Over-charge protection
  • Optional manual maintenance bypass



4. Flexible Monitoring Options



  • LCD display for real-time status monitoring
  • RS232/RS485 and USB communication ports
  • Optional SNMP network monitoring card

High Frequency Online UPS - Premium Power Protection Solution For Financial Institutions 1



5. Robust Construction



  • Triple-protection (dust/moisture/corrosion resistant) coating
  • Designed for harsh environments (tunnels, outdoor applications)



Optional Accessories:



  1. Output isolation transformer (factory installed)
  2. SNMP network monitoring card
  3. Extended battery modules



For more technical details or configuration assistance, please contact our power solutions team.
