3 Compartments IP55 Rated Enclosure Customized Waterproof Power Supply Enclosure

1 set
MOQ
Negotiation
Price
3 Compartments IP55 Rated Enclosure Customized Waterproof Power Supply Enclosure
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: IP55 Rated Enclosure
Cooling System: Air Conditioner With Fans
Cabinet Lock: Anti-theft Three Point Lock
Protection Level: IP55
Material: Galvanized Steel/ Stainless Steel
Sensors: Temp. & Hum. Sensor, Water Sensor, Smoke Sensor, Door Sensor
Illumination: DC48V LED Lamp
Layout: 3 Compartments
Highlight:

3 Compartments IP55 Rated Enclosure

,

IP55 Rated Enclosure Customized

,

Customized Waterproof Power Supply Enclosure
Basic Infomation
Place of Origin: Shenzhen,China
Brand Name: Daxin
Certification: ISO9001,CE,3C,FCC,TLC,IP55
Model Number: ODC-210909C2T
Payment & Shipping Terms
Packaging Details: Woodcase
Delivery Time: 20-40 days
Payment Terms: T/TD/A,Western Union,Paypal,etc
Supply Ability: 3000pcs/month
Product Description

IP55-Rated Three-Compartment Outdoor Cabinet for Energy Storage & Remote Monitoring



Product Description:



Our heavy-duty outdoor cabinet features a robust welded galvanized steel frame with precision engineering for maximum durability. The modular design enables flexible configuration to support diverse telecom equipment including batteries, rectifiers, PDUs, and monitoring systems. With industry-standard dimensions and assembly-type internal structures, it accommodates customized layouts per operational requirements. The corrosion-resistant construction ensures reliable performance in harsh environments, making it ideal for 5G base stations, edge computing nodes, and power distribution applications.



Features:



  1. Welded galvanized steel mainframe
  2. Modular compartment design
  3. Customizable equipment configuration
  4. Corrosion-resistant protection
  5. Standard telecom rack compatibility



Technical Parameters:



Parameter Specification Details
External Dimensions 2400mm(H) × 2000mm(W) × 800mm(D) (84U height)
Compartment Layout - Left: Battery compartment
- Middle: Main equipment
- Right: Secondary equipment
Construction - Material: Galvanized steel sandwich panel
- Outer: 1.2mm steel plate
- Inner: 0.6mm steel plate
- Insulation: 45mm PU foam layer
Cooling System - Primary: 1.2KW AC units ×2
- Secondary: 500W AC unit ×1
- Auxiliary: 12038 fans ×5
Power Distribution - AC distribution box ×1
- 3U embedded DC power supply ×1
Cable Management - DDF frame ×1
- 24-core ODF terminal box ×1
Lighting & Control - LED lights ×3
- Access control switches ×6
Standard Accessories - Heavy-duty support frame
- M12 base screws set
- Anti-vibration square nuts
Thermal Performance Operating range: -40°C to +55°C
Environmental Rating IP55 (Standard), IP65 upgrade available
Weight Capacity - Equipment zone: 1500kg max
- Battery zone: 800kg max





About Us:



3 Compartments IP55 Rated Enclosure Customized Waterproof Power Supply Enclosure 0

3 Compartments IP55 Rated Enclosure Customized Waterproof Power Supply Enclosure 1
